FARSEE TECH PILE HAMMER SERIES Web:www.farsee-tech.com Email:tracy.cui@farseeparts.com/Whatsapp:+8618352940507 | |||||||||
| 1.Product Features: | |||||||||
| 1.Using Q345 manganese steel, high strength and corrosion resistance. 2.The pins are made of 42CrMo alloy steel with high strength and good toughness. 3.Switzerland brand rotating motor . 4.The German Bosch Rexroth hydraulic motor, which is sturdy and durable. 5.American Eaton oil seal, which has a long service life. 6.Korean Autox shock-absorbing block ,which is wear-resistant; 7.Integrated design, safe and stable, low failure rate. | |||||||||
| 2.Specifications： | |||||||||
| Item | Pile hammer | ||||||||
| FEPH1518 | FEPH2028 | FEPH3036 | FEPH3845 | FEPH4555 | FEPH5560 | ||||
| Frequence/rpm | 2800 | 2800 | 2800 | 2800 | 2800 | 2800 | |||
| Centrifugal Force/KN | 280 | 400 | 480 | 580 | 750 | 800 | |||
| Operating pressure/bar | 280 | 300 | 320 | 320 | 320 | 320 | |||
| Working Flow/lpm | 120 | 155 | 168 | 210 | 255 | 255 | |||
| Max turning angel/degree | 180 | 180 | 180 | 180 | 180 | 180 | |||
| Max pile Length/m | 6 | 8 | 12 | 15 | 15 | 18 | |||
| Main body weight/kg | 1290 | 1950 | 2650 | 2900 | 3000 | 3100 | |||
| vice arm weight/kg | 230 | 450 | 650 | 650 | 650 | 750 | |||
| Total weight/kg | 1520 | 2400 | 3300 | 3550 | 3650 | 3850 | |||
| Suitable excavator/T | 15-18 | 20-28 | 30-36 | 38-45 | 45-55 | 55-60 | |||
| 3.Pictures: | |||||||||
